Wagner Tuning Audi Q5 SQ5 Competition Intercooler Kit 3.0 TDI - 200001084

Wagner Tuning Audi Q5 SQ5 Competition Intercooler Kit 3.0 TDI - 200001084

The high performance intercooler has the following core dimension (610mm x 440mm x 65mm) and thus offers a 122% larger cooling surface and 92% more charge air volume compared to the original intercooler. The newly developed competition core granted the adjacent components, for example water cooler, sufficient airflow and is also very light. The end tanks of the intercooler are made of cast aluminium and have been optimised under flow analyses in the CAD system. With the help of additional air baffles, inside inlet, providing for a uniform filling of the intercooler. The result is excellent cooling properties with minimum back pressure. So this kit is just the right thing for racing. The intercooler weighs only 9,1 kg. It is mounted to the original mounting points and is easy to perform (1:1 exchange). Optimum cooling of the charged air with a clear increase in performance! 67mm Inlet and Outlet.

• OEM Intercooler: Cooling Surface 1207,5cm² / Charge-Air-Volume 9,05L
• WT EVO 2 Competition: Cooling Surface 2684cm² / Charge-Air-Volume 17,4L

This Intercooler Kit Suits:

• Audi SQ5 3,0TDI 8R 230KW/313PS 2012-2015 (CGQB)
• Audi SQ5 3,0TDI Competition 8R 240KW/326PS 2015- (CVUB)
• Audi SQ5 3,0TDI Plus 8R 250KW/340PS 2015- (CVUB)
• Audi Q5 3,0TDI 8R 180KW/245PS 2011-2014 (CDUD)
• Audi Q5 3,0TDI 8R 190KW/258PS 2013- (CTBA)

Package Includes:

1 Intercooler
2 silicone hoses
1 Mounting material
1 Installation instruction
